Description
FBT spliitter utilizes precision technology to combine or distribute light from single/multiple inputs to single/multiple outputs bi-directionally. They are designed for power splitting and tapping in telecommunication equipment, CATV network, and test equipment.
Specification
| Product Type | FBT coupler | Fibertyp. | OS2 9/125µm |
| Faserkonfiguration | 1x2 | Split Ratio | 50/50 |
| Wavelength | 1310/1550 | Grade Type | P |
| Faserlänge | 1m | Input/Output Cable | 0.9 |
| Packaging | Steel tube | Band width | ±15nm |
| PDL | ≤0.15dB | Typical Excess Loss | ≤0.01dB |
| Insertion Loss | ≤3.6 dB | Return Loss | ≥ 55 dB |
| Betriebs-Temperatur | -40~85°C | Connector Type | SC/APC |
